What are the differences between "pipe" and "tube"?

The terms "pipe" and "tube" are often used interchangeably, but they refer to different products that serve distinct purposes in engineering, construction, and manufacturing. Below are the key differences between pipe and tube:

1. Purpose and Application

  • Pipe: Pipes are primarily used to transport fluids and gases, such as water, oil, gas, and steam. Their design focuses on the internal diameter (ID), which determines the flow capacity.
  • Tube: Tubes are used in a wide variety of applications, including structural purposes, heat exchangers, medical devices, and instrumentation. Tubes are often selected based on their outside diameter (OD) and wall thickness for strength and structural integrity.

2. Measurement Standards

  • Pipe: Pipes are typically measured by their nominal diameter (a standard that approximates the inside diameter) and schedule (wall thickness). For example, a "2-inch pipe" does not necessarily have a 2-inch inside diameter but follows a standard sizing chart.
  • Tube: Tubes are measured by their exact outside diameter and wall thickness. For example, a "2-inch tube" has an actual outside diameter of 2 inches.

3. Shape

  • Pipe: Pipes are almost always cylindrical to ensure smooth flow of fluids and gases with minimal resistance.
  • Tube: Tubes can be cylindrical, but they also come in various shapes such as square, rectangular, and oval, depending on the application. Non-cylindrical tubes are often used in structural and aesthetic applications.

4. Tolerances

  • Pipe: Pipe manufacturing standards typically allow for looser tolerances because the primary concern is the flow of fluids rather than precise measurements.
  • Tube: Tubes are made to stricter tolerances to meet precise requirements in terms of dimensions, finish, and mechanical properties, which is critical in applications like medical devices and aerospace.

5. Strength and Rigidity

  • Pipe: Pipes are generally designed to handle high-pressure fluid flow, so their strength is gauged based on the pressure they can withstand internally.
  • Tube: Tubes are often designed for structural purposes, so their strength is gauged based on load-bearing capacity and resistance to bending or compression.

6. Material

  • Pipe: Pipes can be made from various materials including steel, copper, PVC, and concrete, depending on the application (e.g., steel for gas, PVC for water).
  • Tube: Tubes are also made from various materials, but they are often made from stainless steel, aluminum, or copper for specialized applications such as medical, aerospace, or industrial settings.

7. Manufacturing Process

  • Pipe: Pipes are generally manufactured through processes like casting or extrusion, and they may undergo less stringent testing compared to tubes.
  • Tube: Tubes undergo more precise manufacturing processes, including drawing or welding, which ensure the exact dimensions and finish required for their intended use.

8. Cost

  • Pipe: Pipes are generally less expensive than tubes because they are manufactured to less precise standards and tolerances.
  • Tube: Tubes tend to be more expensive due to the higher precision in manufacturing and the specific applications that often require specialized materials.

9. Connections

  • Pipe: Pipes are commonly connected using threaded joints, flanges, or welding, with fittings that match the nominal pipe size (NPS).
  • Tube: Tubes are often connected using compression fittings, welding, or other precise methods that maintain the integrity of the material and the exact size.

10. Industry Standards

  • Pipe: Pipes adhere to standards set by organizations like the American Society for Testing and Materials (ASTM), the American National Standards Institute (ANSI), and the American Society of Mechanical Engineers (ASME).
  • Tube: Tubes follow different standards, often defined by ASTM, depending on the application (e.g., ASTM A554 for stainless steel tubing).

Summary

  • Pipe: Primarily used for transporting fluids and gases, measured by nominal size and schedule, with less strict tolerances and often cylindrical in shape.
  • Tube: Used for structural and precision applications, measured by outside diameter and wall thickness, with tighter tolerances and available in various shapes.

Understanding these differences is crucial when selecting the right material for a project, as choosing the wrong one can lead to performance issues, safety hazards, and increased costs.
